dali controller

LTECH Intelligent dimmable led driver have excellent performance:

  • T-PWM digital dimming, maintains CRI(color rendering index).
  • 0~100% flicker-free, High Frequency Exemption.
  • Dimming range from 0-100%, LED start at 0.01% possible.
  • Multi-current & wide voltage, suitable for different power LED.
  • Over temp. / Over voltage / Over load / Short circuit protection,recover automatically.
Adopt revolutionary T-PWM deep dimming technology



CC DALI Dimmable Driver
    • SE-8-350-700-G1D
      SE-8-350-700-G1D
      Rubycon capacitor
      Dimming Interface:DALI-2 DT6, PUSH DIM
      DC Voltage Range:220-240Vdc(Not assessed)
      AC Voltage Range:220-240Vac
      Input Voltage:230Vac
      Power Factor:PF>0.9/230Vac (at full load)
      Efficiency:>78%
      Fluctuation Level:High frequency exemption assessment level.
      Output Voltage:2-18Vdc
      Output Current:350-700mA
      Output Power:0.7-8.4W
      Dimming Range:0~100%，down to 0.01%
      Certification:CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty:5 years
      [field:title/]
      Download Manual


    • SE-10-100-500-W1D
      SE-10-100-500-W1D
      Rubycon capacitor
      Dimming Interface:DALI-2 DT6, PUSH DIM
      DC Voltage Range:100-240Vdc
      AC Voltage Range:100-240Vdc
      Input Voltage:115Vac/230Vac
      Power Factor:PF≥0.95/115Vac(at full load), PF≥0.9/230Vac(at full load)
      Efficiency:80%(at full load)
      Fluctuation Level:No visible flicker/High frequency exemption level
      Output Voltage:9-42Vdc
      Output Current:100-500mA
      Output Power:0.9W-10W
      Dimming Range:0~100%, down to 0.01%
      Certification:CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty:5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-10-500-1000-W1D
      SE-10-500-1000-W1D
      Rubycon capacitor
      Dimming Interface:DALI-2 DT6, PUSH DIM
      DC Voltage Range:100-240Vdc
      AC Voltage Range:100-240Vdc
      Input Voltage:115Vac/230Vac
      Power Factor:PF≥0.95/115Vac(at full load), PF≥0.9/230Vac(at full load)
      Efficiency:78%(at full load)
      Fluctuation Level:No visible flicker/High frequency exemption level
      Output Voltage:2-12Vdc
      Output Current:500-1000mA
      Output Power:1W-10W
      Dimming Range:0~100%, down to 0.01%
      Certification:CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty:5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-6-100-450-G1D
      SE-6-100-450-G1D
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6
      DC Voltage Range: 220-240Vdc
      AC Voltage Range: 220-240Vac
      Input Voltage: 230Vac
      Power Factor:  PF＞0.5/230Vac (at full load),
      Efficiency: 75%
      Fluctuation Level: High frequency exemption assessment level.
      Output Voltage: 9-42Vdc
      Output Current: 100-450mA
      Output Power: 0.9-6.3W
      Dimming Range: 0~100%, down to 0.01%
      Certification: TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-100-250-D2D1
      MT-100-250-D2D1
      Rubycon capacitor
      Dimming Interface:DALI-2 DT6/DT8
      Input Voltage:48Vdc±5% (No polarity)
      Input Current:<0.28A
      Efficiency(Typ):≥87%
      Output Voltage:9-45Vdc
      Output Current:100-250mA
      Output Power:0.9W-11.5W default 9W
      Current Accuracy:+15mA/-25mA
      Standby Power:≤0.5W
      Dimming Range:0-100%,down to 0.1%
      Certification:CE,ROHS
      Warranty:5 years
      [field:title/]
      Download Manual


    • MT-300-450-D2D1
      MT-300-450-D2D1
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      Input Voltage: 48Vdc±5% (No polarity)
      Input Current: <0.57A
      Efficiency(Typ): ≥87%
      Output Voltage: 9-42Vdc
      Output Current:
      300-450mA
      Output Power: 2.7W-18.9W default 16.2W
      Current Accuracy: +15mA/-25mA
      Standby Power: ≤0.5W
      Dimming Range: 0-100%,down to 0.1%
      Certification: CE,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-500-650-D2D1
      MT-500-650-D2D1
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      Input Voltage: 48Vdc±5% (No polarity)
      Input Current: <0.65A
      Efficiency(Typ): ≥87%
      Output Voltage: 9-39Vdc
      Output Current:
      500-650mA
      Output Power: 4.5W-25.35W default23.4W
      Current Accuracy: +5%
      Standby Power: ≤0.5W
      Dimming Range: 0-100%,down to 0.1%
      Certification: CE,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-10-350-700-W1DS
      SE-10-350-700-W1DS
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load),
      Efficiency: 75%(at full load)
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 2-12Vdc
      Output Current: 350-700mA
      Output Power: 0.7W-8.4W
      Dimming Range: 0~100%，down to 0.01%
      Certification: CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-12-100-400-W1DS
      SE-12-100-400-W1DS
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load),
      Efficiency: 82%(at full load)
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 9-42Vdc
      Output Current: 100-400mA
      Output Power: 0.9W-12W
      Dimming Range: 0~100%，down to 0.01%
      Certification: CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-12-350-700-W1DS
      SE-12-350-700-W1DS
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load),
      Efficiency: 82%(at full load)
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 9-24Vdc
      Output Current: 350-700mA
      Output Power: 3.15W-12W
      Dimming Range: 0~100%，down to 0.01%
      Certification: CCC,CB,CE,KC,EAC,RCM,UKCA,BIS,ERP,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-12-100-500-W1D
      SE-12-100-500-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,FCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W2D
      SE-12-100-500-W2D
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W1D
      SE-20-100-700-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,FCC,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W2D
      SE-20-100-700-W2D
      Rubycon capacitor
      Dimming Interface: DALI-2 DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,FCC,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-30-200-800-W1D
      SE-30-200-800-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-40-300-1050-W1D
      SE-40-300-1050-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-450-W1D
      SE-12-100-450-W1D
      Rubycon capacitor
      Dimming Interface: DALI DT6
      Input Voltage: 100-240Vac
      Power Factor:  PF>0.9C/230Vac , at full load PF>0.95C/115Vac , at full load
      Efficiency: >82%@450mA
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-450mA
      Output Power: 0.9W-12W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,RCM,CE,KC,UKCA,BIS,EAC,ENEC,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-30-200-800-W2D
      SE-30-200-800-W2D
      Rubycon capacitor
      Dimming Interface: DALI DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-40-300-1050-W2D
      SE-40-300-1050-W2D
      Rubycon capacitor
      Dimming Interface: DALI DT6/DT8
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.9/230Vac, at full load
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-450-W2D
      SE-12-100-450-W2D
      Rubycon capacitor
      Dimming Interface: DALI-2, DT6/DT8
      Input Voltage: 100-240Vac
      Power Factor:  PF>0.9/230Vac (Foll load)
      Efficiency: >82%@450mA
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-450mA
      Output Power: 0.9W-12W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,ENEC,BIS,TUV,CB,RCM,CE,KC,UKCA,ERP,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • LU-75-500-1750-U1D2
      LU-75-500-1750-U1D2
      Rubycon capacitor
      Dimming Interface: DALI-2, Push DIM
      Input Voltage: 100-240/277Vac (277Vac for North America only)
      Power Factor:  PF>0.97/115Vac; PF>0.95/230Vac; PF>0.9/277Vac
      Efficiency: 89%
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 10-54Vdc
      Output Current: Max. 1.75A
      Output Power: 5-75W
      Dimming Range: 0~100%, down to 0.1%
      Certification: CE,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-350-700-D1D1
      MT-350-700-D1D1
      Dimming Interface: DALI
      Input Voltage: 48Vdc±5% (Not polarity)
      Efficiency: 95%
      Fluctuation Level: No video flicker / High frequency exemption level.
      Output Voltage: 10~42Vdc
      Output Current: 350-700mA
      Output Power: 3.5W-29.4W
      Dimming Range: 0~100%，dimming depth 1%
      Certification: CE,ROHS,FCC
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-100-400-D1D1
      MT-100-400-D1D1
      Dimming Interface: DALI
      Input Voltage: 48Vdc±5% (Not polarity)
      Efficiency: 95%
      Fluctuation Level: No video flicker / High frequency exemption level.
      Output Voltage: 10~42Vdc
      Output Current: 100-400mA
      Output Power: 1W-16.8W
      Dimming Range: 0~100%，dimming depth 1%
      Certification: CE,ROHS,FCC
      Warranty: 5 years
      [field:title/]
      Download Manual




About Us

Product Center

Follow us

Contact Us

  • +86 756 620 8255
  • +86 756 620 8836
  • (Monday to Friday 8:30-18:00)
Legal Disclaimer | Privacy protection | Contact us | Site map
COPYRIGHT © 2003-2025 LTECH. ALL RIGHT RESERVED.
    粤ICP备10035980号    粤公网安备 44049002000101号
