CV Dimmable Driver
  • 36W 12VDC CV Triac LED Driver LM-36-12-L1T2
    Rubycon capacitor
    Dimming Interface: Triac/ELV, Push DIM
    Input Voltage: 108-132Vac
    Power Factor:  PF>0.98/230Vac , at full load
    Efficiency: 84%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 3A
    Output Power: 0-36W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS
    Warranty: 5 years
  • 36W 24VDC CV Triac LED Driver LM-36-24-L1T2
    Rubycon capacitor
    Dimming Interface: Triac/ELV, Push DIM
    Input Voltage: 108-132Vac
    Power Factor:  PF>0.98/230Vac , at full load
    Efficiency: 84%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 1.5A
    Output Power: 0-36W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS
    Warranty: 5 years
  • 60W 12VDC CV Triac LED Driver LM-60-12-L1T2
    Rubycon capacitor
    Dimming Interface: Triac/ELV, Push DIM
    Input Voltage: 108-132Vac
    Power Factor:  PF>0.98/230Vac , at full load
    Efficiency: 86%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS
    Warranty: 5 years
  • 60W 24VDC CV Triac LED Driver LM-60-24-L1T2
    Rubycon capacitor
    Dimming Interface: Triac/ELV, Push DIM
    Input Voltage: 108-132Vac
    Power Factor:  PF>0.98/230Vac , at full load
    Efficiency: 87%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS
    Warranty: 5 years
  • 100W 24VDC CV DALI-2 DT6/DT8 DIM&CT Driver LM-100-24-U2D2
    Rubycon capacitor
    Dimming Interface: DALI-2 DT6/DT8, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 100W 24VDC CV DALI-2 Driver LM-100-24-U1D2
    Rubycon capacitor
    Dimming Interface: DALI-2, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV DALI-2 DT6/DT8 DIM&CT Driver LM-60-12-U2D2
    Rubycon capacitor
    Dimming Interface: DALI-2 DT6/DT8, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV DALI-2 DT6/DT8 DIM&CT Driver LM-60-24-U2D2
    Rubycon capacitor
    Dimming Interface: DALI-2 DT6/DT8, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV DALI-2 Driver LM-60-12-U1D2
    Rubycon capacitor
    Dimming Interface: DALI-2, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV DALI-2 Driver LM-60-24-U1D2
    Rubycon capacitor
    Dimming Interface: DALI-2, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 100W 24VDC CV DMX Driver LM-100-24-U1M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 100W 24VDC CV DMX DIM&CT Driver LM-100-24-U2M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV DMX DIM&CT Driver LM-60-12-U2M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV DMX DIM&CT Driver LM-60-24-U2M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV DMX Driver LM-60-12-U1M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV DMX Driver LM-60-24-U1M2
    Rubycon capacitor
    Dimming Interface: DMX/RDM, Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 100W 24VDC CV 0/1-10V Tunable White Driver LM-100-24-U2A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 100W 24VDC CV 0/1-10V Driver LM-100-24-U1A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 93%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 4.17A
    Output Power: 0-100W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV 0/1-10V Tunable White Driver LM-60-12-U2A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV 0/1-10V Tunable White Driver LM-60-24-U2A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM/CCT
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 12VDC CV 0/1-10V Driver LM-60-12-U1A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 90%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 12Vdc
    Output Current: Max. 5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
  • 60W 24VDC CV 0/1-10V Driver LM-60-24-U1A2
    Rubycon capacitor
    Dimming Interface: 0-10V(1-10V/10V PWM/RX), Push DIM
    Input Voltage: 120-277Vac
    Power Factor:  PF>0.99/120Vac, PF>0.95/230Vac, PF>0.9/277Vac (at full load)
    Efficiency: 91%
    Fluctuation Level: High frequency exemption level.
    Output Voltage: 24Vdc
    Output Current: Max. 2.5A
    Output Power: 0-60W
    Dimming Range: 0~100%, down to 0.1%
    Certification: FCC,CE,ROHS,UL
    Warranty: 5 years
