LTECH Intelligent dimmable led driver have excellent performance:

  • 0~100% flicker-free, High Frequency Exemption.
  • Built-in SCM, dimming curve and smoothing time of power on can be customized.
  • Automatic recognition of 0-10V, 1-10V input signal.
  • T-PWM digital dimming, maintains CRI(color rendering index).
  • Short circuit / Over-heat / Over load / Non-load protection.



CC 0/1-10V Dimmable Driver
    • SE-10-100-500-W1A
      SE-10-100-500-W1A
      Rubycon capacitor
      Dimming Interface:0-10V(1-10V10V PWM,RX)
      DC Voltage Range:100-240Vdc
      AC Voltage Range:100-240Vdc
      Input Voltage:115Vac/230Vac
      Power Factor:PF≥0.95/115Vac(at full load), PF≥0.9/230Vac(at full load)
      Efficiency:80%(at full load)
      Fluctuation Level:No visible flicker/High frequency exemption level
      Output Voltage:9-42Vdc
      Output Current:100-500mA
      Output Power:0.9W-10W
      Dimming Range:0~100%, down to 0.01%
      Certification:CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty:5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-10-500-1000-W1A
      SE-10-500-1000-W1A
      Rubycon capacitor
      Dimming Interface:0-10V(1-10V10V PWM,RX)
      DC Voltage Range:100-240Vdc
      AC Voltage Range:100-240Vdc
      Input Voltage:115Vac/230Vac
      Power Factor:PF≥0.95/115Vac(at full load), PF≥0.9/230Vac(at full load)
      Efficiency:78%(at full load)
      Fluctuation Level:No visible flicker/High frequency exemption level
      Output Voltage:2-12Vdc
      Output Current:500-1000mA
      Output Power:1W-10W
      Dimming Range:0~100%, down to 0.01%
      Certification:CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,ERP,ROHS
      Warranty:5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W1A
      SE-12-100-500-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-12-100-500-W2A
      SE-12-100-500-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 84%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-500mA
      Output Power: 0.9W~12.15W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W1A
      SE-20-100-700-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-20-100-700-W2A
      SE-20-100-700-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac , PF>0.90/230Vac, at full load
      Efficiency: 86%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 100-700mA
      Output Power: 0.9W~20.4W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,FCC,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,PSE,ROHS
      Warranty: 5 years（Rubycon capacitor）
      [field:title/]
      Download Manual


    • SE-30-200-800-W1A
      SE-30-200-800-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-40-300-1050-W1A
      SE-40-300-1050-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-30-200-800-W2A
      SE-30-200-800-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 87%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 200-800mA
      Output Power: 1.8W-30W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-40-300-1050-W2A
      SE-40-300-1050-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V, 10V PWM, RX)
      DC Voltage Range: 120-300Vdc
      AC Voltage Range: 100-240Vac
      Input Voltage: 115Vac/230Vac
      Power Factor:  PF>0.95/115Vac (at full load), PF>0.9C/230Vac (at full load)
      Efficiency: 88%
      Fluctuation Level: No visible flicker/High frequency exemption level
      Output Voltage: 9-42Vdc
      Output Current: 300-1050mA
      Output Power: 2.7W-40W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CB,CE,KC,EAC,RCM,ENEC,UKCA,BIS,CUL,UL,ERP,ROHS
      Warranty: 5 years(Rubycon capacitor)
      [field:title/]
      Download Manual


    • SE-12-100-450-W2A
      SE-12-100-450-W2A
      Rubycon capacitor
      Dimming Interface: 0-10V(1-10V/10V PWM/RX)
      Input Voltage: 100-240Vac
      Power Factor:  PF＞0.95/115Vac, at full load PF＞0.9C/230Vac, at full load
      Efficiency: 82%, at full load
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 9-42Vdc
      Output Current: 100-450mA
      Output Power: 0.9W-12W
      Dimming Range: 0~100%, down to 0.01%
      Certification: CCC,TUV,CE,KC,RCM,ENEC,CB,BIS,EAC,UKCA,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-100-400-D1A1
      MT-100-400-D1A1
      Dimming Interface: 0-10V/1-10V
      Input Voltage: 48Vdc±5% (No polarity)
      Efficiency: 92%
      Output Voltage: 10~42Vdc
      Output Current: 100-400mA
      Output Power: 1W-16.8W
      Dimming Range: 0~100%,down to 1%
      Certification: CE,ROHS,FCC
      Warranty: 5 years
      [field:title/]
      Download Manual


    • MT-350-700-D1A1
      MT-350-700-D1A1
      Dimming Interface: 0-10V/1-10V
      Input Voltage: 48Vdc±5% (No polarity)
      Efficiency: 95%
      Output Voltage: 10~42Vdc
      Output Current: 350-700mA
      Output Power: 3.5W-29.4W
      Dimming Range: 0~100%,down to 1%
      Certification: CE,ROHS,FCC
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-10-350-700-W1A
      SE-10-350-700-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V/10VPWM/RX) 0-10V Interface consumption: <0.05mA
      Input Voltage: 100-240Vac
      Power Factor:  PF>0.95/115Vac , PF>0.8/230Vac,at full load
      Efficiency: 75%
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 2-12Vdc
      Output Current: 350-700mA
      Output Power: 0.7W~8.4W
      Dimming Range: 0~100%, 0.01% dimming depth.
      Certification: BIS,CB,CE,UKCA,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-12-350-700-W1A
      SE-12-350-700-W1A
      Rubycon capacitor
      Dimming Interface: 0-10V (1-10V/10VPWM/RX) 0-10V Interface consumption: <0.05mA
      Input Voltage: 100-240Vac
      Power Factor:  PF>0.97/115Vac , PF>0.85/230Vac, at full load
      Efficiency: 81%
      Fluctuation Level: No video flicker / High frequency exemption assessment level.
      Output Voltage: 10-24Vdc
      Output Current: 350-700mA
      Output Power: 3.5W~12W
      Dimming Range: 0~100%, 0.01% dimming depth.
      Certification: CCC,CB,CE,RCM,TUV,BIS,UKCA,ROHS
      Warranty: 5 years
      [field:title/]
      Download Manual


    • SE-12-100-400-W1A
      SE-12-100-400-W1A
      Rubycon capacitor
      Dimming Interface:0-10V (1-10V/10VPWM/RX) 0-10V Interface consumption: <0.05mA
      Input Voltage:100-240Vac
      Power Factor:PF>0.97/115Vac , PF>0.85/230Vac, at full load
      Efficiency:82%
      Fluctuation Level:No video flicker / High frequency exemption assessment level.
      Output Voltage:10-42Vdc
      Output Current:100-400mA
      Output Power:1W~12W
      Dimming Range:0~100%, 0.01% dimming depth.
      Certification:CCC,CB,CE,RCM,TUV,BIS,UKCA,ROHS
      Warranty:5 years
      [field:title/]
      Download Manual
